特征：
● 12v低电压操作保证实验室安全
● 直流无刷电机免维护
● 转速范围0-3000rpm
● 点动模式和连续模式
特征：
● 12v低电压操作保证实验室安全
● 直流无刷电机免维护
● 转速范围0-3000rpm
● 点动模式和连续模式
产品型号 | CubicB |
运行模式 | 连续操作或点动操作或定时操作 |
振荡方式 | 圆周 |
混匀直径[mm] | 6 mm |
转速范围[rpm] | 0-3000 rpm |
转速显示 | 刻度 |
允许环境温度[°C] | 5-40°C |
允许相对湿度 | 80% |
DIN EN60529保护级别 | IP21 |
电压[VAC] | 200-240 / 115 / 100 V |
频率 [Hz] | 50/60 |
功率[W] | 36 |
电机输入功率[W] | 30 |
电机输出功率[W] | 15 |
外形尺寸（长 x 宽 x 高, mm） | 107x146x166 |
重量[kg] | 3 |
货号 | MI0101002 |
机身颜色选择 | 蓝色 / 灰白 |
产品型号 | CubicB |
运行模式 | 连续操作或点动操作或定时操作 |
振荡方式 | 圆周 |
混匀直径[mm] | 6 mm |
转速范围[rpm] | 0-3000 rpm |
转速显示 | 刻度 |
允许环境温度[°C] | 5-40°C |
允许相对湿度 | 80% |
DIN EN60529保护级别 | IP21 |
电压[VAC] | 200-240 / 115 / 100 V |
频率 [Hz] | 50/60 |
功率[W] | 36 |
电机输入功率[W] | 30 |
电机输出功率[W] | 15 |
外形尺寸（长 x 宽 x 高, mm） | 107x146x166 |
重量[kg] | 3 |
货号 | MI0101002 |
机身颜色选择 | 蓝色 / 灰白 |
